Xhorse XKGHG1EN Masker Garage Remote can support to set frequency, delete code, clone remote, recover data and generate remote. This article is talking about how to check delete codes status, so that we can continue to clone remote.
How to check Delete Code Status?
Before cloning remote, we should check the garage remote status, to make sure remote in deleted code status.
1. Deleted code status: The LED will flash once then go out quickly when keep pressing any button of the garage remote.
2. Delete code operation:
1) Press and hold “Up” & “Down” buttons at the same time, until LED light on. Keep pressing 2 buttons until the LED light off, then release the buttons;
2) Press and hold “Pause”, until LED light on then off. Release the button, delete code successfully.
How to do Remote Cloning?
1. Preparation work
1) Please confirm the garage remote has been in deleted code status. If not, please do above delete code operation first.
2)Make sure the garage remote frequency is same as original remote, in case the remote cloning failed or even remote cloning successful, but the working distance is too short to work well.
2. Remote cloning operation
1) Press and hold any one button of Xhorse Garage Remote, this remote will enter cloning mode, LED will flash once then off (keep pressing the button).
2) Press and hold original remote one button (same button as step1). Put the original remote next to Xhorse garage remote. Once the LED light is on, which means current button cloning is successful.
3)Follow the above steps to clone remote all buttons one by one.
