Xhorse toy8a akl adapter: A must-have for Toyota AKL

Solder-free adapter & cable VVDI Key Tool Plus

This article will introduce you to the latest product released by Xhorse: TOY8A AKL Adapter, a must for Toyota AKL.

Why do you need an Xhorse Toy8a AKL adapter?

The new XM38 Toyota smart key needs data collection and calculation when adding a key, which can be achieved by using VVDI Key Tool Plus, but this function needs to collect data from the ECU on the vehicle, the original OBD 8A Adapter can’t do it, but the Xhorse Toyota 8A Smart Key Adapter can.

Product Introduction:

Xhorse Toyota 8A Smart Key Adapter has two parts: transfer adapter and cables.

The smart authentication unit 89990 on the new smart Toyota has two types of plugs, so the connector has two types: TOY-C1 and TOY-C2.

Xhorse Toy8a Akl Adapter 1

Xhorse Toy8a AKL adapter Support List:

Toyota Transponder 4A:

COROLLA 2019-
LEVIN 2019-
ALLION 2021-

Toyota Transponder 8A with Page4: A8/A9/AA

AVALON 2019- 0410
IZOA 2018- 0410
CROWN 2018- 2110
VELLFIRE 2017- 0120
RAV4 2019.7- 0410
HIGHLANDER 2017- 2110
WILDLANDER 2019- 0410
PRADO 2018- 3330ALPHARD 2017- 0120
LAND CRUISER 2017- 0020/F43
CAMRY 2018- 0410
PRIUS 2018- 0410
C-HR 2018- 0410

Lexus Transponder 8A with Page4: A8/A9/AA

ES 2018- 0440
NX 2017- 2110/F43
GS 2018- 0440
UX 2018- 0440
IS 2017- 2020
LS 2017- 0440
LX 2017- 0010/F43

How to connect Toy8a AKL adapter with Key tool plus?

Step 1. Connect the small end of the TOY-C1 or TOY-C2 cable to the adapter.

Xhorse Toy8a Akl Adapter 2

Step 2. Connect one end of the adapter to the Key Tool Plus.

Xhorse Toy8a Akl Adapter 3

Step 3. Connect the other end of the adapter to the Key Tool Plus main cable.

Xhorse Toy8a Akl Adapter 4

Step 4. Connect the OBD port to the car according to the picture, and connect the other end of the TOY-C1 or TOY-C2 harness to the car ECU.

Xhorse Toy8a Akl Adapter 5

Xhorse Toy8a Akl Adapter 6

For more information on Xhorse XD8ASK TOY8A AKL Adapter, please follow https://www.xhorse.co.uk/
