How to program Audi A4 2013 All Key Lost by VVDI Key Tool Plus?

VVDI Key Tool Plus

Purpose
Using Xhorse VVDI Key Tool Plus Pad to program a key for Audi A4 2013 via OBD when all keys lost.

Steps
Prepare a new smart key &VVDI Key Tool Plus
Connect Key Tool Plus with OBD2 port of vehicle.
Turn ignition on.

Read BCM Data
Immo programming >> Europe >> Audi >> Select by type >> Fifth immobilizer system >> Start programming >> Read BCM data >> Read by OBDII >> Read BCM2 data (OBDII)

If lost all working key, open the headlight, and step on the brake before continue.
OK >> OK

Disconnect the BCM module from power for 2-3 seconds and reconnect again.
Trying to reconnect to BCM…
Press “OK”.

Reading data success.
OK >> Save here >> Rename, OK >> OK

Save file success.
program-audi-a4-2013-all-key-lost-by-xhorse-vvdi-key-tool-plus (1)

program-audi-a4-2013-all-key-lost-by-xhorse-vvdi-key-tool-plus (2)

program-audi-a4-2013-all-key-lost-by-xhorse-vvdi-key-tool-plus (3)

program-audi-a4-2013-all-key-lost-by-xhorse-vvdi-key-tool-plus (4)

program-audi-a4-2013-all-key-lost-by-xhorse-vvdi-key-tool-plus (5)

program-audi-a4-2013-all-key-lost-by-xhorse-vvdi-key-tool-plus (6)

Make Dealer Key
Make dealer key >> A4L, A5, Q5 add key or lost all key – Don’t need working key >> OK >> Load data file, Open >> OK

Put a key into the VVDI Key Tool Plus programmer slot, press “OK”.

Wait writing data until 100%…

Make dealer key success.
Press “OK”.
program-audi-a4-2013-all-key-lost-by-xhorse-vvdi-key-tool-plus (7)

program-audi-a4-2013-all-key-lost-by-xhorse-vvdi-key-tool-plus (8)

program-audi-a4-2013-all-key-lost-by-xhorse-vvdi-key-tool-plus (9)

program-audi-a4-2013-all-key-lost-by-xhorse-vvdi-key-tool-plus (10)

Key Learn
Key learn >> Input the number of keys to be learned, OK >> OK >> Load data file, Open >> OK

Insert dealer key into the ignition(or nearby ignition coil).
Open the headlight, step on the brake before continue.
Press “OK”.

Once a key is learned successfully, X/Y in the dashboard, X will be added 1.

Let’s try the new key, it can work normally.
Key programming has done!
program-audi-a4-2013-all-key-lost-by-xhorse-vvdi-key-tool-plus (11)

program-audi-a4-2013-all-key-lost-by-xhorse-vvdi-key-tool-plus (12)

program-audi-a4-2013-all-key-lost-by-xhorse-vvdi-key-tool-plus (13)

program-audi-a4-2013-all-key-lost-by-xhorse-vvdi-key-tool-plus (14)

program-audi-a4-2013-all-key-lost-by-xhorse-vvdi-key-tool-plus (15)

This is how to add a new key for Audi A4 2013 all keys lost with VVDI Key Tool Plus key programmer.
