Xhorse Mini Prog and VVDI Max Program VW CC 2013 Key on Bench

VVDI Key Tool VVDI PROG

Today, I successfully used Xhorse Mini Prog and VVDI Key Tool Max to program VW CC 2013 Key on Bench.
xhorse-mini-prog-vvdi-max-program-2013-vw-cc-key-01

Look at EEPROM M95320 (pressure) that is removed from the car.
xhorse-mini-prog-vvdi-max-program-2013-vw-cc-key-02

xhorse-mini-prog-vvdi-max-program-2013-vw-cc-key-03

Prepare:
1. Use the tool to clear the chip pin.

2. Connect the device and the adapter.

Put the adapter on the chip (press the light button to turn on the floodlight).
xhorse-mini-prog-vvdi-max-program-2013-vw-cc-key-04

Part 1. Read M95320 (pressure) EEPROM
Meanwhile, on Xhorse APP, switch to Mini Prog, and then click on “EEPROM and Flash” -> ST -> M95XXX -> M95320 (pressure) -> Read -> EEPROM -> Start Operation -> Continue -> Reading completely and save the file.
And you can see “OK” at the back of Mini Prog.
xhorse-mini-prog-vvdi-max-program-2013-vw-cc-key-05

xhorse-mini-prog-vvdi-max-program-2013-vw-cc-key-06

xhorse-mini-prog-vvdi-max-program-2013-vw-cc-key-07

xhorse-mini-prog-vvdi-max-program-2013-vw-cc-key-08

xhorse-mini-prog-vvdi-max-program-2013-vw-cc-key-09

xhorse-mini-prog-vvdi-max-program-2013-vw-cc-key-10

xhorse-mini-prog-vvdi-max-program-2013-vw-cc-key-11

xhorse-mini-prog-vvdi-max-program-2013-vw-cc-key-12

Part 2. Prepare dealer key
Back to Xhorse APP and switch to Keytool Max, tap “Special Function” -> Immo Data Tool -> Asia -> VW -> Passat -> Comfort ID48 – 95320 -> Start Execution ->Local file -> Mini_Prog -> M95320 (pressure) .bin -> Trying to decrypt dump buffer… -> Tick off “Key4 (Unuse)” -> Place the new VVDI Super chip into the keyhole of VVDI Max -> Prepare dealer key -> Tick off “Megamos 48” and tap “Ok” -> Ok -> Prepare dealer key success. It can start engine after writing back new dump file -> Save the new dump file.
xhorse-mini-prog-vvdi-max-program-2013-vw-cc-key-13 xhorse-mini-prog-vvdi-max-program-2013-vw-cc-key-14 xhorse-mini-prog-vvdi-max-program-2013-vw-cc-key-15 xhorse-mini-prog-vvdi-max-program-2013-vw-cc-key-16 xhorse-mini-prog-vvdi-max-program-2013-vw-cc-key-17 xhorse-mini-prog-vvdi-max-program-2013-vw-cc-key-18 xhorse-mini-prog-vvdi-max-program-2013-vw-cc-key-19 xhorse-mini-prog-vvdi-max-program-2013-vw-cc-key-20 xhorse-mini-prog-vvdi-max-program-2013-vw-cc-key-21Part 3. Write M95320 (pressure) EEPROM Completely
Take VVDI Super chip out of the VVDI Max.
Back to the main menu of Xhorse APP, switch to Mini Prog menu, click on “EEPROM and Flash” -> ST -> M95XXX -> M95320 (pressure) -> Write -> EEPROM -> Start Operation -> Tap “Select” to select the write file -> Local file -> Mini_Prog -> M95320 (pressure) .bin -> Back to “Write – EEPROM – M95320 (pressure)” and meanwhile Put the adapter on the chip (press the light button to turn on the floodlight) -> Start Operation -> Continue -> Write completely and you can see “OK” at the back of Mini Prog.
xhorse-mini-prog-vvdi-max-program-2013-vw-cc-key-22 xhorse-mini-prog-vvdi-max-program-2013-vw-cc-key-23 xhorse-mini-prog-vvdi-max-program-2013-vw-cc-key-24

xhorse-mini-prog-vvdi-max-program-2013-vw-cc-key-25Thumb up Xhorse Mini Prog, VVDI Max, VVDI Super Chip. The whole process is smooth and pleasant.
