This post will guide you on how to use VVDI Mini Key Tool to set the frequency of Xhorse Masker Garage Remote.
Step 1. Connect to the device.
Remove the Xhorse logo and loosen the screw.
Then open the shell and take out the PCB board inside.
After pairing MINI Key Tool to the phone via Bluetooth, we connect the device to the masker with a programming cable.
Step 2. Generate copy program.
Tap “Garage Remote” on the app, go to “AA_Xhorse_copy program”, select the last option, then tap “Generate”.
It is worth mentioning that Masker adds an interface to support wired generating, which is more stable than a wireless generation.
So, we don’t need to read the tips for wireless generating.
Just tap “OK” to start the generating.
Step 3. Customise frequency.
After the generate is completed, back to the homepage, tap “Special Function” and go to “VVDI remote function”.
Then we select the last option and start “Garage door key customization”.
First, we read the information about the Masker.
Then we can see the current frequency value in the table.
We just need to tap the frequency value, enter any value you want and tap “Settings” to modify the frequency.
Now we successfully get a remote that sets our required frequency.
For more details, please refer to the video below:
