Xhorse Dolphin XP005 Battery Test is necessary when it won’t turn on after pressing the power button.
Attention: please recharge it for one hour or more
Step 1.Remove 4 Screw two side of base, then remove base armrest
Step 2.Put device on it’s one side, remove the screw marked on picture, remove base
Remove the screw and unplug 3 connector, remember it original place(better take photo before unplug it), when you install need plug it as original
Remove battery, Short-circuit the two pins of the start switch, and use a multimeter to measure the two pins of the output terminal. If there is no 24V voltage output, the battery does not store electricity and needs to be replaced
Hope it helps!
Xhorse Dolphin XP005 tech support: www.xhorse.co.uk.
